5221005 LUNA ECO 1585mm PCO 1x39W 120° 4700lm
LUNA ECO 1585mm PCO 1x39W 120° 4700lm, 4000K, class I, without TW. The inexpensive LUNA ECO diffuser luminaire offers highly efficient lighting with an impact-resistant opalized polycarbonate cover and age-resistant silicone seals. Ideal for 1:1 replacement or as a new installation in workshops, corridors and damp rooms. With simple PRACHT CLAMP SYSTEM.
- Light for everyday life
- EASY. ECONOMIC EFFICIENT.
- Ideal for garages, cellars, warehouses and workshops
- 3-pin TW sets available as accessories
- Simple 1:1 replacement for fluorescent tubes
technical data
| Ausstrahlwinkel | 120 ° |
|---|---|
| REACH (EN) | No |
| Marktkennzeichen | CE |
| Länge | 1585 mm |
| Multi-Lumen (EN) | No |
| IP Schutzart | IP65 |
| IK Schlagfestigkeit | IK08 |
| Interchangeability of operating device | yes, by qualified person |
| Interchangeability of light source | yes, by qualified person |
| Through-wiring | without |
| Outdoor area | Protected outdoor area* |
| Protection class | class I |
| Abmessungen (L x B x H) | 1585 x 74 x 79 mm |
| Dimmable/Controllable | Fixed Output |
| Temperaturbereich | -20 … +35 °C |
| Versorgungsspannung | AC/DC |
| Nennspannung / Frequenz | 220–240V 0/50/60 Hz |
| Vandalism protection | No |
| Animal husbandry | not suitable |
| Umgebungstemperatur (min) | -20 °C |
| Umgebungstemperatur (max) | 35 °C |
| Lichtstrom | 4700 lm |
| Leistung | 39 W |
| Lichtausbeute | 121 lm/W |
| Farbtemperatur | 4000 K |
| Farbwiedergabe Ra | 80 |
| Farbtoleranz (SDCM) | 5 |
| Blendbewertung (UGR 4H 8H) | 23.5 / 24.7 |
| Lebensdauer L70B50 (@Ta 25°C) | 163034 h |
| Lebensdauer L80B50 (@Ta 25°C) | 107053 h |
| Lebensdauer L90B50 (@Ta 25°C) | 58346 h |
| Lebensdauer L70B10 (@Ta 25°C) | 132759 h |
| Lebensdauer L80B10 (@Ta 25°C) | 86939 h |
| Lebensdauer L90B10 (@Ta 25°C) | 46627 h |
| Lebensdauer L70B50 (@Ta max) | 106688 h |
| Lebensdauer L80B50 (@Ta max) | 70100 h |
| Lebensdauer L90B50 (@Ta max) | 37740 h |
| Stoßspannungsfestigkeit L/N-PE | 2.0 kV |
| Zertifizierungszeichen | ENEC |
| Energieeffizienzklasse Lichtquelle | D |
| Leitungsschutz B16A | 32 |
| Leitungsschutz C16A | 54 |
| emergency lighting suitability | no |
| Producer guarantee | 3 Years |
| D marking | Yes |
Tender text
Favorable Diffuser luminaire LUNA ECO 1585mm PCO 1x39W 120° 4700lm 4000K, class I, without TW. The inexpensive LUNA ECO diffuser luminaire offers highly efficient lighting with an impact-resistant opalized polycarbonate cover and age-resistant silicone seals. Ideal for 1:1 replacement or as a new installation in workshops, corridors and damp rooms. With simple PRACHT CLAMP SYSTEM. Item number: 5221005 GTIN: 4018098409601 Technical details/specification: Cover made of PCO - Polycarbonate OPAL; Housing made of PC-Polycarbonate white; 220–240V 0/50/60 Hz; Energy efficiency class D; Number of light sources / LED rows: 1; IP65; Through-wiring in mm²: without; Dimensions: LxWxH: 1585mm x 74mm x 79mm; Diameter: mm
